Plex Setup

13.07.202010 Min Read — InLinux

This post will be mostly documentation for myself, but I also want to share with the world my setup for my personal media server.

Preparation

The inventory for this project is as follows:

  • 1x Bare Metal Server in Frankfurt
  • 1x VPS in Ukraine

My goal is to run the VPS as a 24/7 torrent box, and the baremetal server will then be the plex / storage server.

For torrents themselves, I plan to continue to use qBittorrent, with which I've had good experience with in the past.

For managing TV shows I'm partial to Sickrage / Sickchill or whichever fork is currently active in the community. For movies I prefer Couchpotato, as great as this project is, it is currently unmaintained so if anyone has any suggestions for a project that is at least feature equivalent to Couchpotato that'd be great.

DNS

Before we get to setting up the servers, lets create some DNS entries and point them at the right host.

I use cloudflare for all my DNS management, but the steps will be similiar for most any provider.

We need to create a few subdomains for the services we are about to setup, the names can obviously be changed, this is just how I like naming things.

Go to your DNS overview, click "Create" and make the following subdomains:

  • dl.domain.tld - for qBittorrent
  • movies.domain.tld - for Couchpotato
  • tv.domain.tld - for Sickchill

Server 1

Prerequisites

Let's get started with the VPS. This is a brand new Ubuntu 20.04 installation, so well begin by updating and installing some necessary packages.

sudo apt update && sudo apt upgrade -y
sudo apt install -y vim git net-tools nginx certbot python3-certbot-nginx python2 software-properties-common python-pip-whl

Once we have those, we can get started with the tools. This box will need the following:

First things first, we'll create a user/group for all of these applications to run under

sudo useradd media -g media -u 420 -s /usr/sbin/nologin -Um

This command does a few things for us, first it creates the user media with the GUID 420, then it creates a group with the same name, creates a home directory for it at /home/media and sets the default shell to /usr/sbin/nologin so one cannot login with it - its for application use only.

Next, lets setup some directories for the ongoing and completed downloads:

sudo mkdir -p /opt/{downloads,media}/{tv,movies}
sudo chown -R media: /opt/media
sudo chown -R media: /opt/downloads

qBittorrent

Now we can begin installing stuff. First up - qBittorrent.

There is a version of the headless qBittorrent package in the Ubuntu repos, but its pretty old. So we'll be adding the PPA from qbittorrent themselves.

sudo add-apt-repository ppa:qbittorrent-team/qbittorrent-stable
sudo apt update && sudo apt install -y qbittorrent-nox

Then we must setup a systemd unit file for this,

sudo vim /etc/systemd/system/qbittorrent.service

And copy the following contents in:

[Unit]
Description=qBittorrent Command Line Client
After=network.target

[Service]
#Do not change to "simple"
Type=forking
User=media
Group=media
UMask=0002
ExecStart=/usr/bin/qbittorrent-nox -d
Restart=on-failure

[Install]
WantedBy=multi-user.target

Close vim, and activate this systemd service.

sudo systemctl daemon-reload
sudo systemctl enable qbittorrent
sudo systemctl start qbittorrent

If you get any errors starting it, you can troubleshoot the systemd process with the following command sudo journalctl -xeu qbittorrent

Now qBittorrent should be running on port 8080.

You can run netstat -tlpn to view all open TCP ports to confirm this.

Finally we need to setup the reverse proxy nginx config for this application.

I like to do the certificate first so I don't have to fiddle around with nginx beforehand. To run certbot in standalone mode though, it needs to spin up its own temporary web server, so we need to stop nginx so the ports aren't blocked.

sudo systemctl stop nginx
sudo certbot certonly --standalone -d dl.host.tld -d movies.host.tld -d tv.host.tld
sudo systemctl start nginx

Now we have certificates for our application(s) domains. Make a note of which folder they got saved in exactly. It is usually under: /etc/letsencrypt/live/..., we will need it in the next step for the nginx config.

sudo vim /etc/nginx/conf.d/qbittorrent.conf

Copy in the following and make sure to change dl.domain.tld to the domain you chose!

server {

  listen 80;
  server_name dl.domain.tld;

  return 301 https://dl.domain.tld$request_uri;

}

server {

  listen 443 ssl http2; # managed by Certbot
  server_name dl.domain.tld;

  location /{
    proxy_pass http://127.0.0.1:8080;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
  }

  error_page 404 /404.html;
  location = /404.html {
          root /var/www/html/404;
          # internal;
  }

  ssl_certificate /etc/letsencrypt/live/dl.domain.tld/fullchain.pem; # managed by Certbot
  ssl_certificate_key /etc/letsencrypt/live/dl.domain.tld/privkey.pem; # managed by Certbot
  include /etc/letsencrypt/options-ssl-nginx.conf; # managed by Certbot
  ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem; # managed by Certbot
}

Finally, run a sudo nginx -t to double check the config, and sudo nginx -s reload to reload the config and your qBittorrent instance should be available at the URL of your chosing!

The default login is:

Username: admin Password: adminadmin

You should definitely change that under Tools -> Options -> Web UI as soon as possible.

Then in the Downloads tab of the settings, change the Default Save Path to: /opt/media/ and the Keep incomplete torrents in: option to: /opt/downloads.

Next, close the settings window and in the left hand column menu, right click on Categories and select Add new Category. Here we will add predefined categories for Movies and TV with their respective default save locations, /opt/media/movies and /opt/media/tv. Our other applications, couchpotato and sickchill, will add them to qbittorrent with the category applied and then qbittorrent will know where to download the file to.

Sickchill

This guy is installed by simply cloning their repo. So we will clone this into /opt/SickChill by doing the following

cd /opt
sudo git clone https://github.com/SickChill/SickChill.git
sudo chown -R media: /opt/SickChill

Then we can setup a systemd service file for it.

sudo vim /etc/systemd/system/sickchill.service

And copy the following into it:

[Unit]
Description=SickChill Daemon

[Service]
User=media
Group=media
Type=forking
GuessMainPID=no
ExecStart=/usr/bin/python2 /opt/SickChill/SickBeard.py -q --daemon --nolaunch --datadir=/opt/SickChill

[Install]
WantedBy=multi-user.target

And don't forget to enable the systemd service.

sudo systemctl daemon-reload
sudo systemctl enable sickchill
sudo systemctl start sickchill

If you get any errors starting it, you can troubleshoot the systemd process with the following command sudo journalctl -xeu sickchill

If everything went smoothly, we should have another service running on port 8081. Again, you can use netstat -tlpn to confirm this.

We now need to setup the nginx config file for sickchill as well. Remember in the previous certbot config we already requested the certificates for tv.domain.tld, therefore we can skip that step this time and simply apply the preexisting cert here.

So open up a new nginx config

sudo vim /etc/nginx/conf.d/sickchill.conf

And paste in the following:

server {
  listen 80;
  server_name tv.domain.tld;

  return 301 https://tv.domain.tld$request_uri;

}

server {

  listen 443 ssl http2; # managed by Certbot
  server_name tv.domain.tld;

  location /{
    proxy_pass http://127.0.0.1:8081;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
  }

  error_page 404 /404.html;
  location = /404.html {
          root /var/www/html/404;
          # internal;
  }

  ssl_certificate /etc/letsencrypt/live/dl.domain.tld/fullchain.pem; # managed by Certbot
  ssl_certificate_key /etc/letsencrypt/live/dl.domain.tld/privkey.pem; # managed by Certbot

}

Don't forget to swap out tv.domain.tld for your chosen tv domain.

Now you should be able to visit your page and login with the default user:

Username: sickchill Password: sickchill

This should immediately be updated in the options (gear icon top right) under General.

While we're in the settings, go to Search Settings and select the tab Torrent Search.

Here we have to create the connection to qBittorrent.

So under Send torrents to: select qBittorrent APIv2.

Torrent host:port should be localhost:8080.

Client username and Client password are the web login credentials you selected when setting up qBittorrent earlier.

And finally, the Add label to torrent is the TV category we created in qBittorrent earlier as well, in my case 'TV'.

After that is all entered, you can select "Test Connection" at the bottom of this form to confirm everything is working.

There are a few other settings you should adjust in Sickchill, but I won't go over them here. They are personal settings such as which torrent provider you want to use, what post processing settings like file naming, etc. You can set this up however you like. Just make sure the files are being saved to /opt/media/tv!

Couchpotato

Last, but not least. Couchpotato. This is also simply a matter of cloning their repository:

cd /opt
sudo git clone https://github.com/CouchPotato/CouchPotatoServer.git couchpotato
sudo chown -R media: couchpotato

We also have to install PyOpenSSL,

pip install --upgrade pyopenssl

If pip is not installed, you can install it via sudo apt install python3-pip. This package wasn't available for me, so I installed it manually from pypa.io: cd ~/ && wget https://bootstrap.pypa.io/get-pip.py && python2 get-pip.py

Next, lets setup a systemd service file for couchpotato as well. sudo vim /etc/systemd/system/couchpotato.service

[Unit]
Description=CouchPotato application instance
After=network.target

[Service]
ExecStart=/opt/couchpotato/CouchPotato.py
Type=simple
User=media
Group=media
Restart=always
RestartSec=2s

[Install]
WantedBy=multi-user.target

Then enable it..

sudo systemctl daemon-reload
sudo systemctl enable couchpotato
sudo systemctl start couchpotato
sudo systemctl status couchpotato

If all went well and you did not get any error messages, you should now also have couchpotato running on port 5050.

Now we need to setup the nginx config for couchpotato, sudo vim /etc/nginx/conf.d/couchpotato.conf

Copy in the following:

server {
    listen 80;
    server_name movies.domain.tld;

    return 301 https://movies.domain.tld$request_uri;

}

server {
    listen 443 ssl http2; # managed by Certbot
    server_name movies.domain.tld;

    location / {
      proxy_pass http://127.0.0.1:5050;
      proxy_set_header Host $host;
      proxy_set_header X-Real-IP $remote_addr;
      proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }

    error_page 404 /404.html;
    location = /404.html {
            root /var/www/html/404;
            # internal;
    }

    ssl_certificate /etc/letsencrypt/live/dl.ndo.dev/fullchain.pem; # managed by Certbot
    ssl_certificate_key /etc/letsencrypt/live/dl.ndo.dev/privkey.pem; # managed by Certbot

}

Once this is in place, we can let nginx check its configs again and reload it, sudo nginx -t and sudo nginx -s reload.

Now when we visit our domain, we are greeted with the Couchpotato setup wizard. The most important sections are setting a username / password, and setting up the qBittorrent connection.

Under the section Downloaders, enable the select mark by qBittorrent and enter the following details:

Host: http://127.0.0.1:8080 Username: selected Username Password: selected Password Torrent Label: movies

Once that is up and running we can finally take a breather, grab a coffee, maybe a smoke - because we're 90% of the way finished!

We just need to get the media to our bare-metal server now for long-term storage and playback.

Server 2

To be continued...
